245-1008m³/h ProVent In-Line Duct Mounted Exhaust Fan Exhaust Fan Black in 100mm/125mm/150mm/200mm
1 / 3
245-1008m³/h ProVent In-Line Duct Mounted Exhaust Fan Exhaust Fan Black in 100mm/125mm/150mm/200mm
The high-performance ProVent fantech fan features a compact design that makes them suitable for applications where space is limited. Their mixed-flow impeller provides powerful airflow making them suitable for homes, apartments, and commercial buildings.
Features:
- High performance mixed-flow Impeller.
- Models 150SW and 200SW include an externally mounted 2-speed switch.
- Models 150TSW and 200TSW include a 1-30 minute adjustable run-on timer and externally mounted 2-speed switch.
- The fan body can be removed for maintenance or repair without disturbing the duct system via specially designed support brackets.
- Integrated mounting foot makes installation easier.
- All models include plug and lead for easy plug-in installation.
- Suitable for both supply and exhaust air applications.
| Variations | Speed | m³/h | L/sec | Fan speed RPM | dB (A) @ 3m | Wattage | Voltage |
| 100mm - Standard | High | 245 | 68 | 2220 | 36 | 24w | 240v |
| Low | 202 | 56 | 1860 | 32 | 18w | 240v | |
| 125mm - Standard | High | 360 | 100 | 2280 | 37 | 30w | 240v |
| Low | 270 | 75 | 1920 | 39 | 22w | 240v | |
| 150mm - Standard | High | 576 | 160 | 2520 | 45 | 50w | 240v |
| Low | 443 | 123 | 1980 | 38 | 44w | 240v | |
| 150mm - Run-on Timer | High | 576 | 160 | 2520 | 45 | 50w | 240v |
| Low | 443 | 123 | 1980 | 38 | 44w | 240v | |
| 200mm - Standard | High | 1008 | 280 | 2520 | 51 | 120w | 240v |
| Low | 792 | 220 | 1980 | 44 | 100w | 240v | |
| 200mm - Run-on Timer | High | 1008 | 280 | 2520 | 51 | 120w | 240v |
| Low | 792 | 220 | 1980 | 44 | 100w | 240v |
Select Size
From $49.71
Original: $142.04
-65%245-1008m³/h ProVent In-Line Duct Mounted Exhaust Fan Exhaust Fan Black in 100mm/125mm/150mm/200mm—
$142.04
$49.71Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The high-performance ProVent fantech fan features a compact design that makes them suitable for applications where space is limited. Their mixed-flow impeller provides powerful airflow making them suitable for homes, apartments, and commercial buildings.
Features:
- High performance mixed-flow Impeller.
- Models 150SW and 200SW include an externally mounted 2-speed switch.
- Models 150TSW and 200TSW include a 1-30 minute adjustable run-on timer and externally mounted 2-speed switch.
- The fan body can be removed for maintenance or repair without disturbing the duct system via specially designed support brackets.
- Integrated mounting foot makes installation easier.
- All models include plug and lead for easy plug-in installation.
- Suitable for both supply and exhaust air applications.
| Variations | Speed | m³/h | L/sec | Fan speed RPM | dB (A) @ 3m | Wattage | Voltage |
| 100mm - Standard | High | 245 | 68 | 2220 | 36 | 24w | 240v |
| Low | 202 | 56 | 1860 | 32 | 18w | 240v | |
| 125mm - Standard | High | 360 | 100 | 2280 | 37 | 30w | 240v |
| Low | 270 | 75 | 1920 | 39 | 22w | 240v | |
| 150mm - Standard | High | 576 | 160 | 2520 | 45 | 50w | 240v |
| Low | 443 | 123 | 1980 | 38 | 44w | 240v | |
| 150mm - Run-on Timer | High | 576 | 160 | 2520 | 45 | 50w | 240v |
| Low | 443 | 123 | 1980 | 38 | 44w | 240v | |
| 200mm - Standard | High | 1008 | 280 | 2520 | 51 | 120w | 240v |
| Low | 792 | 220 | 1980 | 44 | 100w | 240v | |
| 200mm - Run-on Timer | High | 1008 | 280 | 2520 | 51 | 120w | 240v |
| Low | 792 | 220 | 1980 | 44 | 100w | 240v |
